CPBg D 35
35HP 100PSI Base Mounted Gear Driven Rotary Screw Air Compressor With DRYER By Chicago Pneumatic (230/460v)
Description
The CPBg 35 base-mounted compressor offers high-performance compressors with excellent reliability and efficiency. Equipped with a new element, premium efficiency motors, and a robust gearbox, these units provide energy-efficient and quiet operation. With options for installation in compressor rooms or near air usage points, the CPBg series ensures easy maintenance and smart monitoring with the ES4000 control unit. These compressors also feature low noise levels, energy recovery capabilities, and optional air quality packages for improved productivity.
Quiet Noise Emission
The CPBg series’ gearbox and insulation allow it to operate optimally while making little noise.
Minimal Upkeep
No more frequent maintenance visits, repairs, or replacement work. The CPBg’s innovative oil separating reduces upkeep significantly.
Intelligent Monitoring
The advanced ES4000 monitoring and control capability is designed to help businesses and operations minimize energy costs. It gives the user complete control over energy usage and provides an intelligent operation shutdown, which reduces energy waste.
Energy Conservation
The CPBg saves more energy while enhancing compressed air generation processes.
Air Quality Packages
Some CPBg models can be equipped with a dryer, water separator drain, and post filter for maximum use.
Standard Features
- Low sound enclosure and pre-filtration panel with foam
- 100, 125, 150, and 175 psig available
- Rapid, single-panel maintenance
- Wye-delta, reduced voltage start
- ES4000 microprocessor control
- Tri-voltage 208-230-460 motor
- Independent oil and air aftercoolers
- Temperature protection on drive side motor bearings
- Improved long life inlet valve
- Shipped with Rotair 2000 hour oil
- Tank and base mount options
- 10 L / 2.64 gal oil capacity
- ASME and cUL approved
Other Features
- Automatic Restart After Voltage Failure
- I/O Expandable
- Service Warnings
- Remote Pressure Sensor Possible
- Remote Monitoring
Tech Specs
- Horsepower: 35hp
- PSI: 100 (Pressure)
- Outlet CFM Max: 171 (Flow)
- Max PSI: 10
- Volts: 230, 460
- Phase: 3
- Fuel: Electric
- Available Options: Base Mounted, Dryer Included
Dimensions & Weight
- Tank Orientation: None
- (A) Length: 52″
- (B) Width: 33″
- (C) Height: 61″
- Weight: 1224 lbs
