SPR 22

22.5HP 145PSI Oil-Free Scroll (Super Quiet) Compressor By Chicago Pneumatic (460v, 64dBA)
Chicago Pneumatic logo

SKU: 8153605095 Categories: ,


Industries like pharmaceuticals, food & beverage, and electronics can benefit from our line of scroll compressors with features like excellent air quality, compactness, easy handling, and low noise level. Our compressors are Class Zero certified (oil-free), have an integrated dryer for moisture removal, and offer a reduced footprint with stacked modules.



  • Class zero certified (no oil) and integrated dryer
  • Stacked modules for a minimized footprint
  • Forklift openings, non-sharp canopy corners, easy access for re-greasing and belt tensioning
  • From 63 to 65 dB(A) sound levels
  • Organized piping


Tech Specs

  • Horsepower: 22.5hp
  • PSI: 145 (Pressure)
  • Outlet CFM Max: 50 (Flow)
  • Max PSI: 145
  • Volts: 460
  • Phase: 3
  • Available Options: Does Not Include Dryer, Base Mounted, 2 Stage


Dimensions & Weight

  • (A) Length: 64.1″
  • (B) Width: 29.5″
  • (C) Height: 72.6″
  • Weight: 1263 lbs
